KM500
KM500 W
Input Voltage
400 V
Mains Voltage Tolerance
-10 /+15 %
Minimum Welding Current
10 A
Maximum Welding Current
500 A
Duty Cycle, 40°C
MIG 500A 40%, TIG 500A 40%, MMA 500A 40%
MIG 420A 60%, TIG 420A 60%, MMA 420A 60%
MIG 360A 100%, TIG 360A 100%, MMA 360A 100%
Open – Circuit Voltage
63 V – 82 V
Factory Delivered Roller
1.0 + 1.2 mm / Steel
Weight
Air-Cooled
77kg
Liquid Cooling, W
100kg
Dimentions (W, L, H)
Air-Cooled
532mm x 948mm x 1031mm
Liquid Cooling, W
532mm x 948mm x 1257mm
Certification
